Description
Headmount temperature transmitters
The PR 533X series transmitters are PC programmable for input and calibration and have excellent prices. They tolerate 85C ambient temperatures, and are fully waterproof – and so suit food manufacturing and other wet environments
PR-5333A is for RTD and resistance and is non isolated. For isolation use the universal transmitter PR5331. PR-5334 accepts all thermocouple types and is isolated to 1500V. PR5343 is designed for level measurement with resistance inputs from 1-100K ohms
PR-5343B is 2-wire level transmitter: Conversion of resistance variation to standard analog current
signals, e.g. from Ohmic level sensors or valve positions.
- RTD and ohm – T/C and mV input
- Extremely high measurement accuracy
- Galvanic isolation on thermocouple version
- Programmable sensor error value
- For mounting in DIN sensor terminal head 33mm hole centres
- Waterproof — PC programmable for Input type and span
- 5 year warranty
DIN rail versions of these transmitters are PR-633X series see DIN rail section
Downloads: Datasheets: 5331 5333A 5333D 5334 5343B Manual: 5331
